Applications:
1) Common usage in 300W include: ring sizing ,retipping prong,repairing bezel setting ,assembling necklace ,bracelets ,eye glass frames, stainless steeel jewellery, filling porosity ,repairing worn up mould insert .
300W is such an incredible tool that gives you an excellent result on welding and patching work that our customers have been full of praises for it risk free repair.
2)The amazing and easy-to-use tool instantly produces a burst of hot light energy with pinpoint accuracy ,The sharply focused light beam melts only a very small area of metal and thus transfer small amount of heat to the other parts of the object.it minimizes the potenitial hazard of heat damage. 3)You no longer need to disassemble the piece ,unset the stone , perform the repair, and then reset the stone .The 300W lets you quickly weld the piece with hot light while holding it in your hand . This enhance model designed with single laser lamps ,and imported main parts of the machine provides long life usage and low maintenance.
Technical Specification:
- Main configuration :The pump source,The laser pulse power supply,Microscope,Professional control system,External Water Chiller
- Power supply : 220V/50Hz/30A/1P
- Maximum peak power : ≤7KW
- Average Pulse Energy : ≤300W
- Wave Length : 1064nm
- Pulse Frequency : 1-10Hz
- Pulse Length : 1-10ms
- Spot diameter : 0.1-2.0mm
- Observation rate : 10 times
- Working distance : 90mm
- Dimension (Main) : 940mm(L)X450mm(W)X1180mm(H)
- Packing size (Main) : 1020mm(L)X520mm(W)X1460mm(H)
- Dimension (Water Chiller) : 610mm(L)X370mm(W)X620mm(H)
- Packing size (Water Chiller) : 710mm(L)X450mm(W)X820mm(H)
- Net Weight (Main) : 145Kg
- Gross Weight(Main) : 180Kg
- Net Weight (Water Chiller) : 46Kg
- Gross Weight(Water Chiller) : 60Kg
- Working requirement : Clean, no dust and vibrate, Temp. :13℃-28℃, Humidity: 5%-75%
- Supplies : Water,electricity,laser lamp
